Beretta Web - Beretta pistol model 4 .357M

Unofficial Beretta Site

Four Barrels Prototype


Probably these are unique pictures of a prototype that never left the Beretta R.&D, department.
Year of production 1983.



space

Beretta pistol model 4 a

Quadruple Barrels Pistol Prototype - Cal. .357 Magnum/ .38 Special - Barrel lenght 84 mm

Beretta pistol model 4 b


Beretta pistol model 4 c







Right side details, hammer lever


Beretta pistol model 4 d







Four Barrels set and and deteils of barrel hinge

Beretta pistol model 4 e







Hammer down for opening and reloading the ammo

  Beretta pistol model 4 f









Left side, note the opening lever and the double action trigger, overall length 150 mm

  Beretta pistol model 4 g Different angol view, note the four chambers and the extractor lifted
Beretta pistol model 4 h Left side, 4 barrels open, note the big looking system and the position of the hammer
